Home > Products > Commercial Plunger Pump > Heavy Duty Triplex Plunger Pump > CE Approval Sewer Cleaning Plunger Pump

CE Approval Sewer Cleaning Plunger Pump

    Payment Type: L/C,T/T,Western Union
    Incoterm: FOB,CFR,CIF,FCA
    Min. Order: 1 Set/Sets
    Delivery Time: 21 Days
Basic Info

Model No.: PF-28

Structure: Radial Plunger Pump

Cylinder Number: Multi Cylinder

Drive Mode: Mechanically Driven Pump

Pump Shaft Position: Horizontal

Type: Radial

Power: Electric, 37 Kw

Male Shaft: 40 Mm

Size: 526x367x253 Mm

Weight: 71 Kg

Speed: 1000 R.p.m

Flow: 93 L/min

Pressure: 210 Bar

Plunger Dia.: 28 Mm

Additional Info

Packaging: Strong Plywood Case, Plastic Bag Cover

Productivity: 1000 SETS/MONTH

Brand: Botuo

Transportation: Ocean,Land,Air,Express Service

Place of Origin: China

Supply Ability: 1000 Sets/ Month

Certificate: CE, CCC

Product Description
CE Approval BOTUO PUMP KF28 Sewer Cleaning Cost Effective 210 Bar Industrial Triplex Ceramic Plunger Pump Descriptions:
The industrial triplex ceramic Plunger Pump is a combination of experienced workmanship and modern technology, it's a symbol of reliability, dependability with lasting service life and minimal downtime, as a pioneer pressure pump, we introduce this pump to many users.


CE Approval BOTUO PUMP KF28 Sewer Cleaning Cost Effective 210 Bar Industrial Triplex Ceramic Plunger Pump Features:

• Triplex Plunger Construction, Available in 5 Versions
• Symmetrical Crankcase Design, Easy [ left to right" Conversion.
• Cast Iron Manifold, Nickel Treated, or 304 Stainless Steel Manifold.
• Die-Cast Aluminum Crankcase.
• Nitrided, Hardened and Tempered Alloy Steel Crankshaft.
• Conical Shaft Bearing
• Aluminum Alloy Connecting Rod
• Stainless Steel Checking Valve
• Anti-Friction Solid Ceramic-Coated Plungers.
• HP Seals



CE Approval BOTUO PUMP KF28 Sewer Cleaning Cost Effective 210 Bar Industrial Triplex Ceramic Plunger Pump Tech Data:


• Solid Shaft, 40mm
• Flow Rate: 92L/min
• Pressure: 210Bar
• Power: 37kw
• Speed: 1000 r.p.m
• Max. Inlet Pressure: 3 Bar
• Max. Fluid Temperature: 40° C
• Inlet Port Thread: 1-1/2``
• Discharge Port Thread: 1``
• Crankcase Oil Capacity: 3.8 liters
• Splash Lubrication
• Weight: 71 kg
• Pump Dimension: 526 mm x 367 mm x 253 mm


CE Approval BOTUO PUMP KF28 Sewer Cleaning Cost Effective 210 Bar Industrial Triplex Ceramic Plunger Pump Applications:

This industrial triplex ceramic Plunger Pumps can be used for many applications, such as:

• High Pressure Municipal Cleaning.
• Car Washing
• Construction Site, Oil Field, Shipyard, Mining, Food Cleaning
• High Pressure Sewer Jetting
• High Pressure Street Cleaning
• Others

Advantage & Benefits:

Innovative & Unique
We are the trend-setter in China for these Triplex Plunger Pumps, we create & design and then introduce them to the market, our products are unique, special and very competitive now.

Cost-Effective & Profitable
Compared to other overseas companies, we have great advantage in pricing, and presently, very few Chinese companies involve in this pump, so it will be a profitable cooperation to work with us.

Stability, Dependability
We grasp all the technology of this Triplex Plunger Pump, and we utilize the highest quality materials & components, which make the pump durable & reliable.

Superior Service & Support

The support & assistance is available anytime, the professional response will be effected soon, the spare parts service will go through with economical method.

Industrial Triplex Plunger Pump

Pf1

Looking for ideal COMET Triplex Ceramic Plunger Pump Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Industrial Triplex Ceramic Coating Plunger Pump are quality guaranteed. We are China Origin Factory of Industrial Triplex Ceramic Coated Plunger Pump. If you have any question, please feel free to contact us.
